Machine:
X/Y/Z axis travel:
U/V axis travel:
Worktable dimensions (W x D):
Worktank dimensions (W x D x H):
Worktank liquid level, Min. to Max:
Worktank capacity:
Max. workpiece weight:
Max. workpiece dimensions:
Distance from floor to table top:
Machine size (W x D x H):
Machine installation dimenesions:
Machine weight:
Air pressure:
Air consumption:
Electricity consumption:
Accuracy, precision:
Controlled axis:
Taper angle:
Wire diameter:
Wire tension
Wire speed:
EDM method:
Max wire weight:

Dielectric tank:
External dimensions (W x D x H):
Weight, empty (main tank):
Capacity:
Filtration method:
Dielectric:
Deionizer:

600 / 400 / 350 mm
150 / 150 mm
836 x 593 mm
1050 x 710 x 350 mm
0 - 325 mm
260 L
1000 kg
1025 x 700 x 330 mm
995 mm
2495 x 3500 x 2345 mm
3880 x 4235 mm
3950 kg
6,5 Bar
-
13 kW, 3-fas, 400 volt
0,0001 mm
4
+/- 25°
ø 0.1 - ø 0.3 mm
3 - 23 N
Max 420 mm/sec
Flushing/submerged
8 kg

725 x 2504 x 1500 mm
600 kg
800 L
3 replaceable paper filters SHF-25E
Water
Harz, barrel of 18 l

Features

options

10 year warranty on positioning accuracy
Linear motor (X, Y, Z, U, V axis)
Absolute linear scales (X, Y, Z, U, V axis)
Sodick motion controller
Ceramic work-zone
Remote controller
3-sided rise and fall work tank
Triple filtration system
Improved ease of operation
Advanced wire tension control
SPW generator
SODICK fine corner control
Energy saving circuit
Digital PIKA W plus for super surface finish
DSF (Dynamic shape first)
Automatic water level control
Fixed jet ATW (automatic wire threader)
Wire end remover
Dielectric cooling unit
Voltage stabiliser
LAN interface
19’’ TFT colour screen
Intelligent Q3vic EDW
Anti-virus software
USB port
Work light
Built-in 20kg wire feeder

0,05 mm wire spec.
HTP high-voltage circuit
Taper flex 45 NEO (for taper cutting up to 45°)
L-cut (wire chopper)
Anti-corrosion system (ANCS)
Espirt CAM software offline (regional option)
Automation system: workpiece changer, electrode changer and robots
Custom Colour
WS4P/5P rotart table (Indexing or simultaneous movement)
8-axis simultaneous control (Factory option)
Active power restart (UPS)
